Vol.13，No.1 环 境 工 程 技 术 学 报 第 13 卷，第 1 期
Jan.，2023 Journal of Environmental Engineering Technology 2023 年 1 月

屈小梭，陈鹏，吴倩，等.SEM 系统引入机动车排放检测可行性研 究 [J].环境工程技术学报，2023，13（1）：129-134.
S
QU X S,CHEN P,WU Q,et al.Feasibility study on the introduction of SEMS technology to motor vehicle emission testing[J].Journal of Environmental
Engineering Technology，2023，13（1）：129-134.

SEM 系统引入机动车排放检测可行性研究
S

1
1
2
1
1
屈小梭 ，陈鹏 ，吴倩 ，包鸿 ，白艳英 ，谢琼 ，吉喆 1*
2
1.中国环境科学研究院机动车排污监控中心
2.泛亚汽车技术中心有限公司
摘要 机动车排放实验室测试与实际道路测试结果间存在较大差距，目前实际道路测试普遍采用车载排放系统（portable
emission measurement system，PEMS）， 但 PEM 系统具有操作复杂、测试装置整体较重等缺点，急需简单易行的实际道路排放
S
测试系统。基于传感器技术的机动车智能排放测试系统（smart emission measurement system，SEMS），结构简单，操作方便，将其
引入机动车实际行驶排放检测非常必要，但国内缺 乏 SEM 系统测试应用相关研究。通过研究国内 外 SEM 系统现状，并开展
S
S
相关对比测试试验，研 究 SEM 系统引入机动车排放检测可行性与存在的问题。结果表明：SEM 系统测试的颗粒物数量（PN）
S
S
与 PEM 测试结果的差异 为 10%～30%；氮氧化物（NO ）排放量与实际道路对比测试结果差异较大，特别是激烈驾驶情况下，最
S
x
大差异高 达 369%；P 和 NO 排放测试结果瞬时分布和累计分布趋势较为一致。基于测试试验及结果分析，探讨 了 SEM 系统
x
N
S
引入机动车排放检测的可行性，提 出 SEM 系统引入机动车排放检测具备一定可行性，可用 于 NO 和 x P 高排放车辆筛查。
S
N
关键词 机动车；机动车智能排放测试系统（SEMS）；排放检测；车载排放系统（PEMS）；可行性
中图分类号：X524 文章编号：1674-991X（2023）01-0129-06 doi：10.12153/j.issn.1674-991X.20210581
Feasibility study on the introduction of SEMS technology to
motor vehicle emission testing
1
2
1
2
1
1
QU Xiaosuo , CHEN Peng , WU Qian , BAO Hong , BAI Yanying , XIE Qiong , JI Zhe 1*
1.Vehicle Emission Control Center, Chinese Research Academy of Environmental Sciences
2.Pan Asia Automotive Technology Center Co., Ltd.
Abstract There is a big gap between the motor vehicle emission laboratory test and the actual road test, and the
actual road test generally uses portable emission measurement system (PEMS) technology, but PEMS test has the
disadvantages of complicated operation and heavy test equipment, and there is an urgent need for simple and easy
actual road emission test technology. Smart Emission Measurement System (SEMS), based on sensor technology for
motor vehicles emission test, has a simple system structure and convenient operation, and it is very necessary to
introduce it into the actual driving emission testing of motor vehicles. There was a lack of SEMS technology testing
and application research in China. By studying the current research status of SEMS technology, and carrying out
comparative test experiments, the feasibility of introducing SEMS technology into motor vehicle emission testing
and the problems were studied. The results showed that the difference between the particle number (PN) tested by
SEMS and PEMS technologies was in the range of 10%-30%. The actual road comparison test results of nitrogen
oxides (NO ) emission had a large deviation, especially in the case of intense driving, and the maximum deviation
x
was as high as 369%. The instantaneous distribution and cumulative distribution trends of PN and NO emission test
x
results were relatively agreeable. Based on the test experiments and result analysis, the feasibility of introducing
SEMS technology into vehicle emission testing was explored, which had certain feasibility and could be used for
NO and PN high-emission vehicle screening.
x
Key words motor vehicles; smart emission measurement system (SEMS); emission testing; portable emission
measurement system (PEMS); feasibility

收稿日期：2021-10-14
基金项目：国家重点研发计划项目（2018YFE0106800）
作者简介：屈小梭（1989—），男，硕士研究生，主要从事机动车污染防治研究，xsqu2009@163.com
* 责任作者：吉喆（1983—），男，高级工程师，主要从事机动车污染防治研究，jizhe@vecc.org.cn
