Page 316 - 《环境工程技术学报》2023年第1期

Vol.13，No.1 环 境 工 程 技 术 学 报 第 13 卷，第 1 期
Jan.，2023 Journal of Environmental Engineering Technology 2023 年 1 月

崔长颢，杨柳阳，王雪娇，等.利用含重金属土壤制备烧结砖可行性及环境安全性研 究 [J].环境工程技术学报，2023，13（1）：312-317.
CUI C H,YANG L Y,WANG X J,et al.Feasibility and environmental safety investigation of making fired bricks by using heavy metals-contained
soil[J].Journal of Environmental Engineering Technology，2023，13（1）：312-317.

利用含重金属土壤制备烧结砖可行性及环境安全性研究

崔长颢 ，杨柳阳 ，王雪娇 ，闫大海 1,2*
1
3
1,2
1.中国环境科学研究院固体废物污染控制技术研究所
2.国家环境保护危险废物鉴别与风险控制重点实验室, 中国环境科学研究院
3.南京工业大学环境科学与工程学院
摘要 为探明利用含重金属土壤作为页岩替代原料制备烧结砖的可行性和环境安全性，选取某砖窑 以 70 % 的比例掺加该土壤
替代页岩开展工业化试验，研究重金属在烟气中的排放情况及在成品砖中的浸出率和分配规律。结果显示：土壤 中 SiO 、
2
Al O 和 3 Fe O 浓度与页岩原料相似，可以用作页岩原料的替代；烧制的成品砖力学性能符合产品质量标准。在以含重金属土
3
2 2
壤为原料的砖块烧结过程中，烟气中常规污染物和重金属污染物排放均满足相关标准，环境风险可控；烧结砖中可浸出重金属浓
度显著低 于 GB 30760—2014《水泥窑协同处置固体废物技术规范》浸出限值，砖块在使用过程中的重金属浸出风险较低；As、
Cd、Cr、Mn、Ni、P 和 b C 在烧结过程中基本赋存在成品砖里，经烟气挥发和湿法脱硫压滤后留存于脱硫滤饼中的重金属含量
u
极低。研究表明，利用含重金属土壤制备烧结砖从产品力学性能及环境安全性上均能满足现有标准，具有一定的资源化利用效益。
关键词 重金属；污染土壤；烧结砖；环境安全性；浸出与分配
中图分类号：X705 文章编号：1674-991X（2023）01-0312-06 doi：10.12153/j.issn.1674-991X.20210613

Feasibility and environmental safety investigation of making fired bricks by using
heavy metals-contained soil

1
3
1,2
CUI Changhao , YANG Liuyang , WANG Xuejiao , YAN Dahai 1,2*
1.Research Institute of Solid Waste Management, Chinese Research Academy of Environmental Sciences
2.State Environmental Protection Key Laboratory of Hazardous Waste Identification and Risk
Control, Chinese Research Academy of Environmental Sciences
3.School of Environmental Sciences and Engineering, Nanjing Tech University

Abstract Soil heavy metal pollution in China is still relatively serious, and inappropriate disposal of heavy metal
contaminated soil can lead to a serious damage to both the ecological environment and human health. However, soil
normally contains a significant amount of SiO , Al O and Fe O , which makes it applicable to prepare sintered
2 2 3 2 3
bricks. In order to ascertain the feasibility and environmental safety of making sintered bricks by using heavy metal
contained soil, an industrialization experiment was carried out in a brick kiln, with a blending ratio of 70% soil to
replace shale, to investigate the heavy metal emission in flue gas, and the leaching and distribution properties in
fired brick. The results revealed that soil had a similar content of SiO , Al O and Fe O compared to shale, and
2
2
3
3
2
therefore, it could be used as a substitute for shale raw materials. The mechanical properties of the fired bricks met
the product quality standards. During the sintering process with heavy metal soil as raw material, the emission of
conventional flue gas pollutants and heavy metal pollutants met the relevant standards, and the environmental risk
was controllable. The concentration of leachable heavy metals in sintered bricks was significantly lower than the
leaching limit of Technical Specification for Cooperative Disposal of Solid Waste in Cement Kilns （GB 30760-2014 ）,
and therefore, the leaching risk was low during using bricks. As, Cd, Cr, Mn, Ni, Pb and Cu basically stayed in fired
bricks under sintering, and the contents of heavy metals remained in the desulfurization filter cake after flue gas

收稿日期：2021-10-26
基金项目：中央级公益性科研院所基本科研业务专项（2019YSKY-016）
作者简介：崔长 颢 (1994—)，男，工程师，硕士，主要从事固体废物环境管理研究工作，2627357570@qq.com
* 责任作者：闫大 海 (1979—)，男，研究员，博士，主要从事固体废物处理技术研究工作，seavsland@163.com
